Bside True RMS Digital Multimeter 3-Line Display Large Screen 8000 Counts Auto-Ranging Ammeter VFC Temperature Capacitance AC/DC Voltage Amp Battery Tester with Flashlight

Features:

• [EBTN LCD Display]: EBTN LCD display greatly enhance the reading experience, the lighted up numbers & letters with black background make it very easy to read, even in bright sunlight or poor light.
• [Large Screen 3 Line Display]: High resolution large screen triple line display can show 3 test results on the screen, such as voltage, frequency and analog bar.
• [Manual & Auto Mode Integrated Design]: Not only suitable for traditional manual switching operation, but also suitable for beginners' no-switching operation.
• [VFC Function]: VFC function can measure the output voltage of inverters.
• [Battery Test & Square Wave Output Function]: Battery test function can more accurately measure battery performance; Square wave generator can output pulse train up to 5MHz.

Details: Features: EBTN LCD display has less eye irritation than other LCD screen. VFC test, battery test, square wave output test Capacitance, temperature, frequency, NCV and diode test AC/DC voltage, AC/DC current, resistance, continuity, and duty cycle test TRMS, auto-ranging, data hold with low battery indication Manual & Auto range Flashlight with 2 back probe holder Max/Min reading Specifications: Display: 8000 counts DC Voltage: 800.0mV/8.000V/80.00V/800.0V/1000V ±(0.5%+3) AC Voltage: 800.0mV/8.000V/80.00V/750V ±(1.0%+3) DC Current: 800.0μA/8.000mA/8.000mA/80.00mA/800.0mA/8.000A/20.00A ±(1.2%+3) AC Current: 800.0μA/8.000mA/8.000mA/80.00mA/800.0mA/8.000A/20.00A ±(1.5%+3) Resistance: 800.0Ω/8.000kΩ/80.00kΩ/800.0kΩ/8.000MΩ±(0.5%+3); 80.00MΩ ±(1.5%+3) Capacitance: 9.999nF/99.99nF/999.9nF/9.999μF/99.99μF/999.9μF ±(5.0%+20); 9.999mF/99.99mF ±(5.0%+5) Frequency: 9.999Hz/99.99Hz/999.9Hz/9.999kHz/99.99kHz/999.9kHz/9.999MHz ±(0.1%+2) Duty Cycle: 1%~99% ±(0.1%+2) Temperature: (-20~1000)℃/(-4~1832)℉ ±(2.5%+5) Square wave output: 50Hz~5000Hz Diode: show the forward voltage NCV: alarm beep sounds and LED blink if detect AC voltage Continuity: alarm beep sounds if resistance less than 50Ω Power: 1.5V (AA) x 3 (not included) Size: 176mm * 91mm * 47mm Weight: 360g Package Includes: 1 * Digital Multimeter 1 * Probes 1 * Thermocouple 1 * Carrying Case 1 * User Manual Note: The batteries are not included in the package due to Aviation Security Check
